Advantech Intel E-2276ME, 3.5″ MIO SBC, HDMI+DP+LVDS (MIO-5393RE6C-U8A1)
Deskripsi
| Category | Attribute | Value |
| Display | DP/HDMI | DP 1.2 (up to 4096×2304 @ 60Hz), HDMI 1.4 (up to 4096×2160 @30Hz) |
| Display | eDP* | Max resolution up to 4096 x 2304 at 60 Hz |
| Display | LVDS | Dual channel 24-bit LVDS, max resolution up to 1920 x 1200 with 60Hz |
| Display | Multi-Display | Triple simultaneous displays with 48-bit LVDS/eDP + HDMI + DP |
| Memory | ECC Support | Yes |
| Memory | Max. Capacity | 64GB (up to 32GB per SO-DIMM) |
| Memory | Socket | 2 x 260 Pin DDR4 SO-DIMM |
| Memory | Technology | DDR4 2400MHz SO-DIMM |
| Processor | Base Frequency | 2.8 GHz |
| Processor | BIOS | AMI UEFI 256 Mbit |
| Processor | Chipset | Intel CM246 |
| Processor | Core Number | 6 |
| Processor | CPU | Intel Xeon E-2276ME |
| Processor | CPU TDP | 45W |
| Processor | LLC | 12MB |
| Processor | Max Turbo Frequency | 4.5 GHz |
| Processor | Thread | 12 |
| Storage | M.2 | M.2 B key (type 2242 & 2280) |
| Storage | SATA | 2, up to 6.0 Gb/s (600 MB/s) |
| Operating System | Ubuntu | V |
| Environment | Humidity | Operating: 40° C @ 95% relative humidity, non-condensing; Storage: 60° C @ 95%relative humidity, non-condensing |
| Environment | Non-Operational Temperature | -40 ~ 85° C and 60° C @ 95% RH Non-Condensing |
| Environment | Operational Temperature | 0 ~ 60° C (32 ~ 140° F) (Operational humidity: 40° C @ 95% RH Non-Condensing) |
| Environment | Vibration Resistance | 3.5 Grms |
| Power | Battery | Lithium 3 V / 210 mAH |
| Power | Connector | Default ATX 2x2P, DC jack supported by request |
| Power | Power Consumption (Idle) | TBD |
| Power | Power Consumption (Max) | TBD |
| Power | Power Management | ACPI |
| Power | Power Supply Voltage | Supports single 12V input, ± 10% |
| Power | Power Type | Single 12V DC power input |
| Ethernet | Connector | 2 RJ45 on Rear I/O |
| Ethernet | Controller | GbE1: Intel i219, GbE2: Intel i210 |
| Ethernet | Speed | 10/100/1000 Mbps |
| Security | TPM | TPM2.0 (Infineon SLB9665) |
| Graphics | 3D/HW Acceleration | 3D: DX 2015/11.2/11.1/10/9 ; OpenGL4.5; OpenCL 2.0/1.2/1.0 HW Decode: AVC/H264, VC1/WMV9, MPEG2, HEVC/H265 (8/10 bits), VP8, JPEG/MJPEG, VP9 HW Encode: AVC/H264, MPEG2, HEVC/H265, VP8, JPEG, VP9 |
| Graphics | Base Frequency | 350 MHz |
| Graphics | Chipset | Intel UHD Graphics P630 |
| Graphics | Controller | Intel Gen 9 LP |
| Graphics | Max. Frequency | 1150 MHz |
| Audio | Amplifier | Optional via MIOe |
| Audio | CODEC | High Definition Audio (HD), Line-in, Line out, Mic-in |
| Watchdog Timer | 65536 level timer interval, from 0~65535 sec, multi-level, multi-option watchdog timer | |
| Certification | EMC | CE, FCC |
| Expansion | M.2 | 1 x B key (Type: 2280, 3042) + 1 x E Key (Type: 2230) |
| Expansion | MIOe | DDI x 1, 4 PCIe x1, USB 3.0, USB 2.0, LPC, SMBus, Rest, Line-out, Power on |
| Internal I/O | CAN bus | 1 |
| Internal I/O | FAN | 1 x 4-Wire Smart Fan, 12V@2A |
| Internal I/O | Front Panel Control | Power LED, HD LED, Reset, Power Switch, Case Open, Buzzer |
| Internal I/O | GPIO | 2 x 8-bit |
| Internal I/O | I2C | 1 |
| Internal I/O | Inverter | 1 |
| Internal I/O | SATA | 6 (SATA III) |
| Internal I/O | Serial | 1 (RS-232/422/485 autoflow control) |
| Internal I/O | SMBus | 1 |
| Internal I/O | USB2.0 | 2 |
| Physical Characteristics | Dimensions (L x W) | 146 x 102 mm (5.7″ x 4″), same as 3.5″ |
| Rear I/O | DC Jack* | 1 (Optional) |
| Rear I/O | DP/HDMI | 1/1 |
| Rear I/O | Ethernet | 2 |
| Rear I/O | LED | Power, HDD |
| Rear I/O | Serial | 1 RS232/422/485 support auto flow control |
| Rear I/O | USB | 4 x USB 3.1 (Gen.2, 10Gbps) |
Informasi Tambahan
| Brand |
Advantech |
|---|
