Cisco IE 4000 4 x RJ45 10/100M, 4 x PoE 10/100M, 4 x 1G Combo, LA (IE-4000-4T4P4G-E)
Rp101.265.300
IE-4000-4T4P4G-E Specification |
|
|
Total Ports |
12 |
|
GE combo uplinks (4G) |
4 GE combo uplink ports (Combo ports provide one copper and one fiber physical port and only one can be activated at a time.) |
|
RJ-45 copper ports (T) |
4 FE |
|
PoE/PoE+ ports (P, GP), Maximum PoE power budget |
4 FE, 125W |
|
Default software |
LAN Base feature set (Can be upgraded to IP Services at a fee.) |
|
Hardware |
● 1GB DRAM ● 128-MB onboard flash memory ● 1-GB removable SD flash memory card ● Mini-USB connector ● RJ-45 connector |
|
Alarm |
Alarm I/O: two alarm inputs to detect dry contact open or closed, one alarm output relay |
|
Power Input |
● Redundant DC input voltage with operating range: nominal 9.6 to 60VDC ● Maximum DC input current: 3.7A |
|
Power consumption |
35W |
|
Dimensions (H x W x D) |
6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm) |
|
Weight |
6.35 pounds (2.88 kg) |
|
Switch performance and scalability |
|
|
Forwarding rate |
Line rate for all ports and all packet sizes |
|
Number of queues |
4 egress |
|
Unicast MAC addresses |
16,000 |
|
IGMP multicast groups |
1,000 |
|
Number of VLANs |
1,000 |
|
IPv4 MAC security ACEs |
1,000 with default TCAM Template |
Cisco Industrial Ethernet 4000 Switches-series-data-sheet.pdf
